March 2026 Numbers: NT$415.19 Billion, 45% YoY

TSMC disclosed March 2026 monthly revenue of NT$415.19 billion on April 10, 2026 — a 45.2% year-over-year increase and a 30.7% sequential jump from February. Translated at current exchange rates, the single-month figure approaches $12.9 billion USD, a number that rivals the quarterly revenues of the largest semiconductor equipment companies in the world. The March release finalizes TSMC's first quarter of 2026 and confirms the company is tracking well above its own guidance midpoint.

The magnitude of the sequential swing — 30.7% month-over-month — reflects a combination of accelerating AI chip shipments, the continued ramp of the 2nm (N2) process node, and a recovery in advanced packaging throughput after tool qualification bottlenecks in early Q1. Analysts at Trendforce and Seeking Alpha had projected a strong March print; the actual figure exceeded consensus expectations.

Full Q1 2026: NT$1.13 Trillion — AI Demand Rewrites the Record Books

TSMC's cumulative Q1 2026 revenue reached NT$1,134.10 billion, equivalent to approximately $35.2 billion USD. That represents roughly 38% year-over-year growth for the full quarter. TSMC had guided for $34.6–$35.8 billion at its January earnings call; the company is landing comfortably within that band. Gross margin guidance for Q1 stands at 63–65%, with operating margin projected at 54–56% — levels that reflect the pricing power of the 2nm and 3nm nodes, where TSMC has no direct competitor at volume scale.

The 3nm node (N3E) accounted for approximately 28% of wafer revenue in Q4 2025, up from 22% in Q1 2025. CoWoS advanced packaging — TSMC's hybrid bonding and wafer-on-wafer interconnect platform used in AI accelerators — has grown to represent roughly 10% of total revenue, an extraordinary figure for what was previously a niche packaging business. TSMC is projecting AI-related revenue at a mid- to high-50s percent compound annual growth rate through 2029.

$52–56 Billion in Capex: Where the Equipment Dollars Are Going

TSMC's 2026 capital expenditure plan of $52–56 billion — a 30% year-over-year increase — is the direct mechanism translating revenue growth into equipment orders. Approximately 70–80% of TSMC capex flows to advanced process tools: lithography scanners, etch systems, deposition chambers, metrology platforms, and process control equipment. At the midpoint of $54 billion, TSMC alone accounts for roughly 40% of projected global 300mm wafer fab equipment spending for 2026, which SEMI estimates at $133 billion.

Fab 22 in Kaohsiung is the primary 2nm production site: Phase 1 is in volume production, Phase 2 is completing equipment installation and entering trial production, and Phase 3 structural construction is largely complete. Fab 20 in Baoshan is running at 20,000–25,000 2nm wafers per month and scaling. Both fabs are on track for the year-end target of 140,000 2nm wafers per month across all phases. Meanwhile, Fab 18B (3nm) continues Phase 7 and Phase 8 expansion in Tainan, adding additional etch and deposition capacity for N3P and N3X customers including Apple, Nvidia, and AMD.

2nm Ramp and CoWoS: The Two Demand Engines

The 2nm gate-all-around (GAA) architecture is the most process-step-intensive node TSMC has ever manufactured. Each GAA transistor requires nanosheets formed by alternating silicon and silicon-germanium layers, which are then selectively etched in a multi-step sequence involving atomic layer etch (ALE), isotropic plasma etch, and highly selective CVD dielectric fill. Industry analysts estimate that 2nm wafers require 15–20% more total deposition and etch steps than equivalent 3nm wafers, driving proportional increases in tool utilization and chamber count.

CoWoS advanced packaging is the second major demand driver. The platform requires copper redistribution layer (RDL) deposition via PVD and electroplating, barrier/seed ALD layers for through-silicon via (TSV) fill, and plasma surface activation before bonding. TSMC is targeting 150,000 CoWoS wafers per month by the end of 2026 — a fourfold increase from late 2024 — and has advanced packaging fabs AP5B in Taichung and AP7 in Chiayi both progressing on schedule. Every incremental 10,000 CoWoS wafers per month requires meaningful additional deposition and etch capacity.

What This Means for Plasma Processing and Thin Film Deposition

Plasma processing equipment (etch, PECVD, plasma activation): TSMC's 2nm GAA ramp is the single largest near-term demand driver for plasma etch tool suppliers. The nanosheet formation process requires dielectric ALE and plasma clean steps that did not exist in FinFET flows. Lam Research's Kiyo and Flex etch platforms, Applied Materials' Centris, and Tokyo Electron's Vigus systems are the primary tools deployed for these steps. Each of TSMC's 2nm fab phases requires hundreds of etch chambers; Fab 22 Phase 2's equipment installation currently underway represents a multi-hundred-million-dollar tool order wave. Plasma activation — used in CoWoS bonding preparation — is a growth area for lower-cost plasma tools in TSMC's advanced packaging fabs, where unit volumes are high and surface uniformity requirements are strict.

Thin film deposition systems (ALD, CVD, PVD, sputtering): The 2nm high-k/metal gate stack requires more ALD cycles than any previous node. TSMC's GAA devices use hafnium-based high-k dielectrics (deposited by ALD) and work-function metal fills (deposited by ALD and CVD) around all four sides of each nanosheet — a geometry that demands exceptional conformality and cycle-count precision. ASM International's Pulsar and Emerald ALD platforms and Applied Materials' Centura Nanocure systems are heavily deployed in these steps. PVD targets for cobalt, tungsten, and ruthenium barrier layers are under sustained demand pressure; sputtering target manufacturers supplying TSMC's Tainan and Kaohsiung fabs have reported extended lead times through 2026.

The equipment supply chain (plasma sources, targets, vacuum components, gas delivery): TSMC's $54 billion capex cycle creates second-order demand throughout the equipment supply chain. Vacuum pump suppliers (Edwards, Pfeiffer, Ebara) are seeing extended delivery windows for turbomolecular and dry pump systems. Specialty process gas demand — particularly NF3 for chamber cleaning, HBr and Cl2 for silicon etch, and TDMAT and TEMHF for ALD metal precursors — is tracking well above 2025 levels. Process monitoring suppliers including Nova, Onto Innovation, and Nanometrics are fulfilling metrology tool orders tied to TSMC's new fab phases. The revenue surge TSMC reported today is not an abstraction for equipment suppliers — it is the downstream validation of equipment investments already in motion.
